Specifications
| Model | REA506 | REA813 |
| Outer diameter(mm) | Ø185 | Ø340 |
| Maximum speed (rpm) | 6000 | 4000 |
| Spindle nose | A2-5 | A2-8 |
| Through hole diameter(mm) | 56.5 | 91 |
| Bearing inner diameter (mm) | Ø90 Ø75 | Ø140 Ø115 |
| Bearing lubrication method | grease | grease |
| Motor Specifications | 160x110x220 | ATE AC270/250/8 |
| Motor power S1 (kW) | 11 | 22 |
| Motor torque S1 (Nm) | 74.9 | 477.5 |
| Cooling method | Oil Cooling | Oil Cooling |
| Weight(kg) | Approx. 250 | About 360 |
| Optional | Brake disc | Brake disc |
While listed models are standardized catalog spindles, customized spindle specifications are available. Welcome to contact us for your individually customized designs for any use.
