Specifications
| Model | RB3002 | RB3021 | RB4006 | RB4002 | RBH004 | RB4078 | RBH018 | RB5002 | RB5004 | RB5029 |
| Outer diameter(mm) | Ø100 | Ø120 | Ø120 | Ø150 | Ø150 | Ø155 | Ø155 | Ø155 | Ø190 | Ø200 |
| Maximum speed (rpm) | 15000 | 15000 | 12000 | 12000 | 12000 | 12000 | 12000 | 8000 | 10000 | 10000 |
| Taper hole specifications | BT30 | BBT30 | BT40 | BT40/BBT40 | HSKA63 | BT40/BBT40 | HSKA63 | BT50/BBT50 | BT50/BBT50 | BT50/BBT50 |
| Pulling force (kgf) | 300±50 | 300±50 | 700±50 | 1000±100 | 2050±250 | 1000±100 | 2050±250 | 1500±100 | 1800±100 | 1800±100 |
| Bearing inner diameter (mm) | Ø50 | Ø60 | Ø60 | Ø70 | Ø70 | Ø70 | Ø70 | Ø80 | Ø100 | Ø90 |
| Bearing lubrication method | grease | grease | grease | grease | grease | grease | grease | grease | grease | grease |
| Cooling method | Oil Cooling | Oil Cooling | Oil Cooling | Oil Cooling | Oil Cooling | Oil Cooling | Oil Cooling | Oil Cooling | Oil Cooling | Oil Cooling |
| Weight(kg) | Approx. 17 | Approx. 20 | Approx. 33 | Approx. 56 | Approx. 56 | Approx. 60 | Approx. 60 | Approx. 70 | Approx. 123 | Approx. 130 |
| Center water outlet | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional |
While listed models are standardized catalog spindles, customized spindle specifications are available. Welcome to contact us for your individually customized designs for any use.
