High processing accuracy
- High dynamic rotation accuracy
- Balance correction within G1, low vibration
- Easy to modularize
- Small thermal displacement and high stability
- The whole machine is short in height and has small inertia
High processing efficiency
- High spindle power and large moment of inertia
Specifications
| Model | REH128 | REH098 |
| Outer diameter(mm) | Ø210 | Ø235 |
| Maximum speed (rpm) | 15000 | 15000 |
| Taper hole specifications | HSKA63 | HSKA63 |
| Pulling force (kgf) | 2000±250 | 2000±250 |
| Bearing inner diameter (mm) | Ø70 | Ø70 |
| Bearing lubrication method | grease | grease |
| Motor Specifications | ATF IM160/170/6(380V) | SIEMENS 1FE 1093-4WN11 |
| Motor power S1 (kW) | 28.3 | 28 |
| Motor torque S1 (Nm) | 60.1 | 75 |
| Cooling method | Oil Cooling | Oil Cooling |
| Weight(kg) | Approx. 170 | Approx. 170 |
| Center water outlet | Optional | Optional |
While listed models are standardized catalog spindles, customized spindle specifications are available. Welcome to contact us for your individually customized designs for any use.
