Specifications
| Motel | RT4002 | RT5006 |
| Outer diameter(mm) | Ø150 | Ø190 |
| Maximum speed (rpm) | 8000 | 8000 |
| Taper hole specifications | BT40 | BT50 |
| Pulling force (kgf) | 1000±100 | 1800±100 |
| Bearing inner diameter (mm) | Ø70 | Ø100 |
| Bearing lubrication method | grease | grease |
| Cooling method | Oil Cooling | Oil Cooling |
| Weight(kg) | Approx. 65 | Approx. 110 |
| Center water outlet | Optional | Optional |
While listed models are standardized catalog spindles, customized spindle specifications are available. Welcome to contact us for your individually customized designs for any use.
