Specifications
| Model | RA4007 | RA5005 | RA6023 | RA8001 | RA1113 | RA1503 |
| Housing OD (mm) | Ø150 | Ø170 | Ø200 | Ø260 | Ø286 | Ø400 |
| Max. Speed (rpm) | 8000 | 6000 | 5000 | 3500 | 2800 | 1000 |
| Nose | A2-4 | A2-5 | A2-6 | A2-8 | A2-11 | A2-15 |
| Spindle Bore Hole (mm) | 45 | 56 | 66 | 92/98 | 117.5 | 184 |
| Bearing ID (mm) | Ø70 | Ø80 | Ø100 Ø90 | Ø130 Ø120 | Ø160 Ø150 | Ø240 Ø220 |
| Lubrication | grease | grease | grease | grease | grease | grease |
| Weight(kg) | Approx. 47 | Approx. 75 | Approx. 90 | Approx. 200 | Approx. 313 | Approx. 610 |
| Options | Brake disc/encoder | Brake disc/encoder | Brake disc/encoder | Brake disc/encoder | Brake disc/encoder | Brake disc/encoder |
While listed models are standardized catalog spindles, customized spindle specifications are available. Welcome to contact us for your individually customized designs for any use.
