Specifications
| Model | RD4187 |
| Outer diameter(mm) | Ø150 |
| Maximum speed (rpm) | 12000 |
| Taper hole specifications | BBT40 |
| Pulling force (kgf) | 1260±60 |
| Bearing inner diameter (mm) | Ø70 |
| Bearing lubrication method | grease |
| Cooling method | Oil Cooling |
| Weight(kg) | Approx. 58 |
| Center water outlet | Optional |
While listed models are standardized catalog spindles, customized spindle specifications are available. Welcome to contact us for your individually customized designs for any use.
